50Ω SMPM Male RF Connector 0.3MHz-40GHz 170V for RG405

Brand Name : ELT

Model Number : SSMP-KB2-1

Certification : ISO9001, IS014001

Place of Origin : Xi'an, China

MOQ : MOQ 100 pieces

Price : The price depend on the quantity

Payment Terms : T/T,L/C,D/P

Supply Ability : As requirements

Delivery Time : 8-12 weeks for new production

Packaging Details : 100pcs/bag or plastic bottle;100pcs/carton as requirement

Product Name : SMPM Male Cable Connectors

Model : SSMP-KB2-1

Frequency Range : 0.3MHz-40GHz

Impedance : 50Ω

Rated Voltage : 170v

DWV : 500V

Insulation Resistance : ≥5000MΩ

Center Conductor : Copper Alloy, Gold Plated

Outer Conductor : Copper Alloy, Gold Plated

Samples : Available，In Stock

Contact Now

50Ω SMPM Male RF Connector 0.3MHz-40GHz 170V for .086 Cable or RG405

The SMPM coaxial connector features a compact design engineered for small package requirements, making it ideal for high data rate applications. Its superior shielding reduces signal interference, ensuring optimal transmission at elevated speeds. When used with an SMPM female-to-female adapter, this connector system provides reliable board-to-board connections while compensating for radial and axial misalignments during installation.

Product Specifications

Item	Value
Product Name	SMPM Male Cable Connector
Model	SSMP-KB2-1
Frequency Range	0.3MHz-40GHz
Impedance	50Ω
Rated Voltage	170V
DWV	500V
Insulation Resistance	≥5000MΩ
Center Conductor	Copper Alloy, Gold Plated
Outer Conductor	Copper Alloy, Gold Plated
Mating Cable	.086 or RG405

Product Outline Dimensions (Unit: mm)

50Ω SMPM Male RF Connector 0.3MHz-40GHz 170V for RG405

Applications

Microwave communication systems
Measurement equipment
Aerospace applications
Radar systems
Electronics fields

Elite Electronic manufactures SMPM connectors using premium materials and rigorous quality control to ensure exceptional durability and reliability in extreme environments.

Packaging & Shipping

Each SMPM connector is carefully packaged in protective cartons to ensure safe transit. We use reliable courier services with tracking numbers provided for all shipments.

For model availability and additional series options, please contact us at sales3@xa-elite.com.cn.

Note: While some models are in stock, all catalog-listed models can be produced quickly upon request.
